R17IK3S-SPM169
Panel PC con chasis PCAP de acero inoxidable IP69K Intel® Core™ i5-7200U de 17 pulgadas

Name: Panel PC con chasis PCAP de acero inoxidable IP69K Intel® Core™ i5-7200U de 17 pulgadas | R17IK3S-SPM169
Brand: Winmate
SKU: R17IK3S-SPM169

El Winmate R17IK3S-SPM169 es un PC de panel con chasis PCAP de acero inoxidable IP69K de 17 pulgadas con procesador Intel® Core™ i5-7200U, diseñado para el control de máquinas, la automatización de fábricas y las interfaces hombre-máquina (HMI) para operadores. Este producto ayuda a los compradores industriales, fabricantes de equipos originales (OEM) e integradores de sistemas a seleccionar una solución Winmate fiable para entornos resistentes, integrados o de misión crítica en los que el rendimiento, la durabilidad y la disponibilidad a lo largo de un ciclo de vida prolongado son fundamentales. Ideal para: El R17IK3S-SPM169 es ideal para el control de máquinas, la automatización industrial y las interfaces HMI para operadores, especialmente cuando los equipos necesitan una integración de hardware estable, un funcionamiento sobre el terreno fiable y un proveedor con experiencia en informática industrial. Especificaciones clave: Entre las características más destacadas del producto se incluyen una pantalla táctil PCAP de 17" con resolución de 1280 x 1024, Intel® Core™ i5-7200U Kaby Lake a 2,5 GHz (con turbo hasta 3,1 GHz), acero inoxidable SUS 316 / AISI 316 para las industrias alimentaria y química, certificación IP69K completa, puertos impermeables con cables adaptadores para conectividad externa y compatibilidad con montaje VESA/YOKE. Intención de búsqueda SEO: Este contenido está optimizado para usuarios que buscan R17IK3S-SPM169, Winmate R17IK3S-SPM169, PC de panel industrial Winmate, PC de panel industrial, PC de panel industrial de 17 pulgadas e Intel® Core™ i5-7200U, así como para consultas con intención de compra relacionadas con hardware Winmate de grado industrial, informática resistente, sistemas integrados y soluciones de productos listas para su aplicación.

Descontinuado (EOL)

El modelo R17IK3S-SPM169 ha sido descontinuado y reemplazado por el R17IT3S-SPM169 Para obtener más información, por favor contáctenos.

CARACTERÍSTICAS PRINCIPALES

Pantalla táctil PCAP de 17 pulgadas 1280 x 1024
Intel® Core™ i5-7200U Kaby Lake, 2,5 GHz (de turbo a 3,1 GHz)
Acero inoxidable SUS 316 / AISI 316 para industrias alimentarias y químicas
IP69K completo
Puertos impermeables con cables adaptadores para conectividad externa
Admite montaje VESA/YOKE
Admite modo guante/lluvia
Unión óptica (opcional)

CERTIFICATIONS

FICHA TÉCNICA RECURSOS

AÑADIR A LA CONSULTA

AÑADIR PARA COMPARAR

R17IK3S-SPM169

Panel PC con chasis PCAP de acero inoxidable IP69K Intel® Core™ i5-7200U de 17 pulgadas

EOL

Resumen Especificación

Winmate IP69K Stainless PCAP Chassiss Panel PC R17IK3S-SPM169 with Waterproof and Dustproof

Waterproof All-Around

The Panel PC fully complies with IP69K water and dust resistance to survive splashing conditions during stringent cleanup processes and strict hygiene demands in the Food, Beverage, and Pharmaceutical industries.

Winmate IP69K Stainless PCAP Chassiss Panel PC R17IK3S-SPM169 with Comprehensive Applications

Comprehensive Stainless Solution

The wide range of stainless human-machine interfaces (HMI) and Panel PCs are widely used for automation processes in Food & Beverage applications and chemical factories.

Winmate IP69K Stainless PCAP Chassiss Panel PC R17IK3S-SPM169 with PCAP Touch

Projected Capacitive Multi-Touch (P-CAP)

The highly-sensitive touch screen and PCAP multi-touch support make it easy for users to key in data, rotate images, drag and drop files, and zoom in with two or more fingers.

Display

Size

17 inches

Touch / Glass

Projected Capacitive Multi Touch Screen

Resolution

1280x1024

Panel Brightness

350 nits

Contrast Ratio

1000:1

View Angles

85,85,80,80

Active Area

337.920x270.336 mm

System Specification

Processor

Intel Core i5-7200U 2.5GHz (up to 3.1GHz) (Default)
Intel Core i5-7300U 2.6GHz (up to 3.5GHz) (Optional)

Memory

1 x SO-DIMM, DDR4 2133 MHz, 4GB (Default)
8GB (Optional)
16GB (Optional)

Storage

1 x M.2 2242 SSD 128GB (Default)
M.2 2242 SSD up to 512GB (Optional)

Ethernet controller

2 x Intel® Ethernet Controller

Security

TPM 2.0

Operating System

Windows 10 IoT Enterprise (64 bit) (Optional)
Linux Ubuntu 20.04 (Optional)

WLAN

Support (Optional)

Mechanical

Dimension

412 x 344 x 61.3 mm

Mounting

VESA Mount
Yoke Mount

Enclosure

Stainless Housing

Cooling System

Fanless design

Environment

Operating Humidity

10% to 90% RH, Non-Condensing

Operating Temperature

0°C to 45°C

Storage Temperature

-20°C to 60°C

IP rating

IP69K

Certification

CE, FCC

IO Ports

USB Port

1x M12 Waterproof Connector for 2 x USB2.0

Serial Port

1 x M12 waterproof connector for RS232

LAN

1 x Waterproof Giga LAN RJ45 Connector

Indicator

1 x LED Indicator for power
1 x LED Indicator for storage

Control

Button

1 x Power Button
1 x Reset Button

Accessory

100~240V AC to DC Adapter with waterproof connector
Power Cord
External USB cable with waterproof connector
External COM cable with waterproof connector
External LAN cable with waterproof connector
Waterproof caps
Manual
VESA screws

Power

Power Rating

12V DC (M12 type)

Winmate’s technological capabilities include the ability to design waterproof Panel pc products, and our focus in this field has resulted in the IP69K Stainless Panel PC and Display series. Designed for applications with high hygienic requirements such as the food and beverage industry, the IP69K Stainless Panel PC contains the highest obtainable IP rating where the product is able to withstand close-range high pressure, high temperature spray downs. This level of protection allows for easy cleaning and sterilization using water with temperatures of up to 80°C and pressure of up to 30 Bar. The housing for this IP69K Stainless Panel PC is made from stainless steel to resist against corrosion and liquids with a true flat, easy-to-clean front surface. Waterproof connectors covered by protective caps and an air venting valve to prevent moisture from building up within the housing make up the rest of the external housing to allow for full IP69K protection. With the option for Intel Core i5-7200U Kaby Lake, Intel Bay Trail-M N2930 or in a display configuration, the Winmate IP69K Stainless Panel PC goes beyond allows for powerful computing in a package that goes beyond that of a standard industrial panel computer. For those that work in the food and beverage processing industry or chemical manufacturing, the ability for the machine controller panel PC to withstand high pressure, high temperature washdowns to ensure a sanitized clean environment helps to make the manufacturing process more efficient. For more details and questions on Winmate’s IP69K stainless Panel PC solution, feel free to contact us for more information.
